Technical Parameters
|
Build Envelope |
1300mm×650mm×1700mm Incl. 100mm Substrate |
|
Variable Layer Thickness |
20 ~ 100μm |
|
Laser Power |
IPG 1000W × 8; 1000W × 10; 1000W × 12 |
|
Scanner |
Scanlab High-speed Scanner |
|
Field Lens |
Sill f-θ Lens |
|
Recoater |
Variable Speed Powder Recoater<Two-way> |
|
Laser Beam Quality |
M2≤ 1.1 |
|
Scanning Speed |
≤ 4 m/s |
|
Build Rate |
≥200cm³/h Octa Laser; ≥250cm³/h Ten Laser ≥300cm³/h Twelve Laser |
|
Power Dissipation |
≤25kw |
|
Available Material |
Superalloy, Aluminum Alloy, Titanium Alloy, Stainless Steel, Die Steel,copper Alloy, Magnesium Alloy, Cobalt Chromium Alloy, Permalloy, Invar Alloy, Etc |
undefined
Equipment Advantages
4 guide rail and high precision dual drive synchronous control, to achieve stable operation of large format forming platform.
Multiple Laser Configurations
Standard 8 laser, optional 10, 12 laser.
High Precision Forming Platform
The positioning accuracy can be controlled within ± 0.005mm.
Intelligent Monitoring
Powder bed monitoring module, the abnormal spread of powder for automatic powder replenishment, automatic alarm.
Long-lasting Filtration System
Filter life of more than 100000 hours, to achieve equipment printing uninterrupted.
Automatic Powder Circulation System
Automatic screening and drying powder; automatic and efficient completion of powder recovery, screening, supply; fast completion of powder cleaning work.
Related Cases
At the end of May this year, the radium laser LiM-X650H equipment was successfully rolled off the production line and put into use in Hubei Sanjiang Aerospace Hongyang Electromechanical Co., Ltd., which is of positive significance in promoting the research and development and upgrading of domestic additive manufacturing equipment. It is of positive significance for radium laser to deeply understand the user's needs, verify the application of large-format metal additive manufacturing equipment, and promote the upgrade iteration of metal additive manufacturing equipment.
